Model 41

Article number: CU.aerial.41.001

Outdoor rugged antenna for the Mymesh 2.4GHz mini-BLC node. Including a 1 meter integrated RF cable with an SMA male connector.

Installation

  • bolt through

    • Technical

    Electrical
    SMA male connector
    Wireless
  • Mymesh 2.4GHz
  • omni-directional
    • Dimensions
  • ø37 x 77mm
  • max. material thickness: 11 mm
    • IP rating
    IP65

    Certification

  • CE marked

    • Features

  • Easy installation
  • Suitable for outdoor use
  • 1 meter cable
  • available with different cable length (special)
  • Operating temperature -20 - +65°C

    • Options

  • integral rubber washer for exterior use

    • Works with:

    mini-BLC DALI

    Alternative:

    OLC-Z
